Beschreibung
Features
- Stable output power
- 4 Power levels up to 1600mW
- 40 Channels (including Raceband)
- Fast frequency lock, no startup interference with other pilots
- Built-in output power self-check functionality
- VTX telemetry with IRC Tramp protocol
Tips
VTX is set to 25mW by default! Power levels above 25mW require a HAM license or have to be approved by local authorities!
Please ensure you’re flying legal frequencies and use our prepared Betaflight VTX tables according to your region.
Specifications
- Input voltage: 7V～34V
- Interface: IPEX
- Power levels: PIT/25mW/400mW/800mW/1600mW
- Channels: 40 (including Raceband)
- Mounting pattern: 25.5×25.5mm/Φ1.6
- Lightweight: 16.5g (excluding antenna)
- VTX telemetry: IRC Tramp
- Betaflight IRC Tramp Configuration: Please download the attached VTX table for Betaflight!
- RC Tramp VTX table values: 25mW/400mW/800mW/1600mW
Packing List
- 1 x BLITZ Whoop 1.6W VTX
