Beschreibung
Specification and main feature
ESC:
- MCU EFM8BB21F16G,pipelined 8-bit C8051 core with 50 MHz maximum operating frequency.
- Default ESC firmware: Bluejay, A-H-30 (Using Bluejay configurator).
- Support for loading firmware: BLHeli-S,A-H-30 (Using BLHeliSuite).
- Dimensions: 34x34mm.
- Install holes: 25.5×25.5mm,26.5×26.5mm,M2.
- Weight: 9.6g.
- 4in1 ESC is highly integrated with F7 Flight Control. Ultra small size, especially suitable for small multi rotor.
- Bluejay firmware supports Dshot300 & Dshot600.
- BLHeli-S code supports regular 1-2ms pulse width input, as well as Oneshot125, Oneshot42 and Multishot , supports all Dshot .
- ESC maximum speed is limited to 500k eRPM (BLHeli-S firmware).
- Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling (BLHeli-S firmware).
Flight controller:
- FC firmware: STM32F7X2 (Config.：FLYCOLORF7_AIO_HD).
- MCU: STM32F722.
- Gyro: MPU-6500.
- USB: Micro USB.
- Spare pad for USB, supporting additional soldering of external USB.
- Simplified circuit design, only retaining support for HD image transmission (not supporting analog image transmission).
- Integrated Vbat,3.3V,5V, for HD VTX, receiver, buzzer, LED and other devices.
Part list:
- Raptor AIO HD x 1
- 2mm vibration absorber x4
- Power wire (XT60) x1
- Electrolytic capacitor x1
- Connecting wire(HD TX) x1
