Beschreibung
HGLRC Racewhoop25 2.5″ FPV Racing Drone Black analog version Caddx Ratel 2 FPV Camera Zeus 350mW VTX
Features:
*Made of composite material, super explosion resistant;
*Fluorescent effect, 3 colors optional, ultra-high color value;
*With 2004 motor, super powerful and violent;
*2.5 Inches Racewhoop frame, compact and fly anywhere you want;
*Racewhoop Structure design, strong and No damage to the the frame or the components.
*Power plug:XT30
Product Name:HGLRC Racewhoop25 FPV Racing Drone 4S/6S Analog version
Weight:217.1g
HGLRC Racewhoop25 Frame
Culvert ring: Black / Purple / Turquoise
Model:2.5 inches Racewhoop Frame
Wheelbase:125mm
Size:167*167mm
Zeus F722 mini flight controller
Gyro:BMI270
Input voltage:3-6S Lipo
BEC output:5V/2A, 9V1A
Firmware:HGLRCF722
Zeus 28A BL_S ESC
Input voltage:3-6S
Continuous current:28A
Peak current:35A (10 seconds)
Firmware:BLS-F-H-40
Zeus 800mW VTX
Output Power:PIT/25/100/200/400/800mW
Input Voltage:DC6-26V
Antenna:MMCX
Caddx Ratel 2 Camera
Image Sensor:1/1.8 “ 1200TVL CMOS
Input Power:DC 5-40V
Dimensions:19mm*19mm*20mm
AEOLUS 2004 3000KV motor
Motor:KV3000
Input voltage:4-6S
Recommended props:2.5 inches
Mounting hole:4*M2-∅12
HQ Prop T63mm 2.5 inch 6-blade propeller
Quantity:4 CW & 4 CCW
Package includes:
1x Zeus F722 mini flight controller
1x Zeus 28A BL_S ESC
4x AEOLUS 2004 3000KV motor
1x Racewhoop25 Frame
1x Zeus 800mW VTX
1x Caddx Ratel 2 Cam
8x HQ Prop T63mm 6-blades propellers
1x mini Hammer Antenna (RHCP)
1x Receiver (optional)
Recommended battery:
6S:550mah-1000mAh
See manual here
