It’s finally here, the iFlight Commando 8 with fully integrated iFlight ExpressLRS hardware! No additional external module necessary to run ELRS. If you’re planning to run another TX module, please checkout the optional add-on external module bay.
ExpressLRS TX modules developed in close cooperation with the ExpressLRS Team with firmware targets already released.
Checkout the official ExpressLRS website: https://www.expresslrs.org
Official ExpressLRS Quick Start: https://www.expresslrs.org/2.0/quick-start/getting-started/
Remember this is an Open Source Project and therefore free to use for everyone. If you want to support the Developers, please consider donating: https://opencollective.com/expresslrs
Features
Internal iFlight ExpressLRS (ELRS) transmitter (additional fan for cooling)
Market’s lowest crystal frequency deviation (low packet loss, high frequency stability)
Highest quality digital hall sensor gimbals for maximum precision
High-performance PCB Single and Dual Band (900/2400MHz) radio antennas
Inbuilt 4000mAh for up to 20h power (2x 2000mAh 18650 batteries)
Stock EdgeTX firmware with pre-installed Lua scripts
Several Gimbal Stick Ends available (stock 18mm)
Performance and Compatibility
Please use iFlight ELRS receivers coupled with our transmitter for maximum performance! We’ve probably achieved
market’s best crystal frequency stability at a very low frequency deviation (only 11KHz in total at 51.99976MHz on the
crystal). Please checkout this article for further information https://github.com/ExpressLRS/ExpressLRS/wiki/Crystal
Oscillator-(XO)-Frequency-Error
ELRS Only Option (Single TX)
Single ELRS option includes 1x ELRS TX module (please select band) pre-installed in the back of the radio Cooling fan is
inside the flat back cover Single Band or Dual Band antenna option (for future upgrades or module changes) Dual
Band antenna option for convenient multi band use without changing the antenna
Antenna
Single-Band (2.4GHz)
Button Functionality
2x 5-axis menu buttons for full OpenTX or EdgeTX control
2x 2-position switches (can be used for arming; not momentary)
2x 3-position switches
RF Power
2.4GHz system: SX1280
ExpressLRS 2.4GHz // Max Output 500mW
Radio Channels: 8
Input: Mini High Precision Digital Hall Gimbals with NMB bearings
